Brass Plate
Overview
MEI rolls heavy-gauge brass plates from 6 mm to 80 mm thickness with sound internal structure and uniform hardness, suitable for machining, engraving, and structural applications. Because we cast our own bars, plates are free of the porosity and inclusions that plague material rolled from purchased scrap slabs — and every lot ships with chemical and mechanical test reports.
SIZE RANGE
| Parameter | Min | Max |
|---|---|---|
| Thickness | 6.00 mm | 80.00 mm |
| Width | 50 mm | 1300 mm |
| Length | — | 2500 mm (cut to size) |
GRADES OFFERED
| MEI Grade | Alloy / Common Name | Cu (%) | Pb (%) | India IS | ISO | USA ASTM | Japan JIS | UK BS |
|---|---|---|---|---|---|---|---|---|
| MEI-60 | 60/40 Muntz Metal | 59.00–61.00 | ≤0.100 | IS 422 | CuZn40 | C28000 | C2801 | CZ109 |
| MEI-63 | 63/37 Yellow Brass | 62.00–64.00 | ≤0.050 | IS 410 | CuZn37 | C27200 | C2720 | CZ108 |
| MEI-63L | 63/37 Lead-free Brass (Pb ≤50 ppm) | 62.00–64.00 | ≤0.005 | IS 410 | CuZn37 | C27200 | C2720 | CZ108 |
| MEI-65 | 65/35 Yellow Brass | 64.00–66.00 | ≤0.050 | IS 410 | CuZn35 | C27000 | C2680 | CZ107 |
| MEI-70 | 70/30 Cartridge Brass | 69.00–71.00 | ≤0.050 | IS 410 | CuZn30 | C26000 | C2600 | CZ106 |
| MEI-80 | 80/20 Low Brass | 79.00–81.00 | ≤0.030 | — | CuZn20 | C24000 | C2400 | CZ103 |
| MEI-85 | 85/15 Red Brass | 84.00–86.00 | ≤0.050 | — | CuZn15 | C23000 | C2300 | CZ102 |
| MEI-90 | 90/10 Commercial Bronze | 89.00–91.00 | ≤0.020 | IS 2768 | CuZn10 | C22000 | C2200 | CZ101 |
| MEI-95 | 95/05 Gilding Metal | 94.00–96.00 | ≤0.020 | IS 3167 | CuZn5 | C21000 | C2100 | CZ125 |
Zn = remainder in all grades. Leaded brass plate (MEI-58 / MEI-59) available — see Leaded Brass page.
TEMPER REFERENCE
| Temper | VPN (Vickers Hardness) |
|---|---|
| Soft | 55 – 70 |
| LHA | 75 – 85 |
| HA (Quarter Hard) | 90 – 110 |
| HB (Half Hard) | 110 – 130 |
| HD (Full Hard) | 130 – 165 |
| HE (Extra Hard) | 165 – 175 |
| HS (Spring Hard) | 180 – 220 |
APPLICATIONS
Machined components, engraving and etching plates, moulds and dies, bushings and wear plates, valve and pump parts, marine hardware, and architectural elements.
WHY MEI
Full-thickness soundness verified through our QA lab on plates up to 80 mm, custom cut sizes to minimise your machining allowance, and consistent machinability lot after lot.
